T24DAB

T24DAB; His Master's Voice (ID = 2425108) Radio

T24DAB; His Master's Voice (ID = 2425109) Radio

T24DAB; His Master's Voice (ID = 2425110) Radio

T24DAB; His Master's Voice (ID = 2425111) Radio

T24DAB; His Master's Voice (ID = 2425112) Radio

T24DAB; His Master's Voice (ID = 2425113) Radio

T24DAB; His Master's Voice (ID = 2425114) Radio

T24DAB; His Master's Voice (ID = 2425115) Radio

T24DAB; His Master's Voice (ID = 2425116) Radio
T24DAB; His Master's Voice (ID = 2377844) Radio T24DAB; His Master's Voice (ID = 2377845) Radio
Use red slider bar for more.
T24DAB; His Master's Voice (ID = 2377844) Radio
His Master's Voice: T24DAB [Radio] ID = 2377844 1400x1706
Select picture or schematic to display from thumbnails on the right and click for download.
For model T24DAB, His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB

Country:  Great Britain (UK)
Manufacturer / Brand:  His Master's Voice (Masters, HMV, H.M.V., Marconi); Hayes, Middlesex, GB
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: X17 W17 ZD17 N18
Main principle Superheterodyne (common); ZF/IF 365 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Line / Batteries (any type) / 90 & 5 x 1.5 or 195-215; 216-235; 236-255 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: T24DAB - His Master's Voice Masters,
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 11.75 x 3.875 x 9 inch / 298 x 98 x 229 mm
Notes A metal rectifier is used for H.T.
The weight below includes batteries.
This model was exported to Australia.
Net weight (2.2 lb = 1 kg) 9.5 lb (9 lb 8 oz) / 4.313 kg
Circuit diagram reference Australian Official Radio Service Manual Vol. X

Model page created by Stuart Irwin. See "Data change" for further contributors.
