Junior

Junior ; Holzinger & Co. GmbH (ID = 191407) Kit

Junior ; Holzinger & Co. GmbH (ID = 191408) Kit
Junior ; Holzinger & Co. GmbH (ID = 2431948) Kit Junior ; Holzinger & Co. GmbH (ID = 2431952) Kit
Junior ; Holzinger & Co. GmbH (ID = 2431949) Kit Junior ; Holzinger & Co. GmbH (ID = 2431951) Kit
Junior ; Holzinger & Co. GmbH (ID = 2431950) Kit Junior ; Holzinger & Co. GmbH (ID = 191406) Kit
Use red slider bar for more.
Junior ; Holzinger & Co. GmbH (ID = 2431948) Kit
Holzinger & Co. GmbH: Junior [Kit] ID = 2431948 1400x1604
Select picture or schematic to display from thumbnails on the right and click for download.
For model Junior, Holzinger & Co. GmbH, Max - Radio Holzinger (Maho); München

Country:  Germany
Manufacturer / Brand:  Holzinger & Co. GmbH, Max - Radio Holzinger (Maho); München
Year: 1960 ? Category: Kit (Parts plus instruction) or building instructions only
Semiconductors (the count is only for transistors) 3: OC169 OC169 GFT32
Main principle Super-Heterodyne (Super in general); 2 AF stage(s); Reflex
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Junior - Holzinger & Co. GmbH, Max -
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 94 x 68 x 30 mm / 3.7 x 2.7 x 1.2 inch
Notes

Das Gerät entspricht dem TR3 von Vogel-Elektronik, dem TR3 von Radio-Fern und der EVA von H+S. Von Radio-RIM gab es diesen Bausatz mit dem Aufdruck RIM.

Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Collectors' prices
Mentioned in Heinz Richter, Das grosse Transistor-Bastelbuch

Model page created by Günther Stabe. See "Data change" for further contributors.
