For model Neutrovox 4 Röhren, Horny (Hornyphon); Wien:
Hornyphon Neutrovox

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1926/1927 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4:
Main principle TRF without regeneration
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 4;50;90;130 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Neutrovox [4 Röhren] - Horny Hornyphon; Wien
Material Wooden case
Notes Lassen Sie sich bei den Fotos durch die manchmal in die Buchsen rechts eingesteckten Teile nicht verwirren.
Price in first year of sale 570.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
