Prinz 16

Prinz 16; Horny Hornyphon; (ID = 26238) Radio

Prinz 16; Horny Hornyphon; (ID = 339583) Radio

Prinz 16; Horny Hornyphon; (ID = 1526648) Radio

Prinz 16; Horny Hornyphon; (ID = 1526649) Radio
Prinz 16; Horny Hornyphon; (ID = 2145261) Radio Prinz 16; Horny Hornyphon; (ID = 3532) Radio
Prinz 16; Horny Hornyphon; (ID = 133962) Radio Prinz 16; Horny Hornyphon; (ID = 133960) Radio
Prinz 16; Horny Hornyphon; (ID = 133955) Radio Prinz 16; Horny Hornyphon; (ID = 133958) Radio
Prinz 16; Horny Hornyphon; (ID = 1526647) Radio Prinz 16; Horny Hornyphon; (ID = 1532442) Radio
Prinz 16; Horny Hornyphon; (ID = 1532443) Radio Prinz 16; Horny Hornyphon; (ID = 1532444) Radio
Use red slider bar for more.
Prinz 16; Horny Hornyphon; (ID = 2145261) Radio
Horny Hornyphon;: Prinz 16 [Radio] ID = 2145261 1102x1315
Select picture or schematic to display from thumbnails on the right and click for download.
For model Prinz 16, Horny (Hornyphon); Wien:
Bild aus eigener Sammlung

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1934/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: AK1 E444 E443H 506
Main principle ZF/IF 128 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Loudspeaker
Power out
from Radiomuseum.org Model: Prinz 16 - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Notes nur Export Schweiz?
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.


All listed radios etc. from Horny (Hornyphon); Wien
Here you find 867 models, 775 with images and 584 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
