Prinz 35W II/1

Prinz 35W II/1; Horny Hornyphon; (ID = 26251) Radio

Prinz 35W II/1; Horny Hornyphon; (ID = 9622) Radio

Prinz 35W II/1; Horny Hornyphon; (ID = 108999) Radio

Prinz 35W II/1; Horny Hornyphon; (ID = 1718808) Radio
Prinz 35W II/1; Horny Hornyphon; (ID = 228722) Radio Prinz 35W II/1; Horny Hornyphon; (ID = 228725) Radio
Prinz 35W II/1; Horny Hornyphon; (ID = 228724) Radio Prinz 35W II/1; Horny Hornyphon; (ID = 228723) Radio
Prinz 35W II/1; Horny Hornyphon; (ID = 570728) Radio Prinz 35W II/1; Horny Hornyphon; (ID = 570729) Radio
Prinz 35W II/1; Horny Hornyphon; (ID = 570730) Radio Prinz 35W II/1; Horny Hornyphon; (ID = 570732) Radio
Prinz 35W II/1; Horny Hornyphon; (ID = 570733) Radio Prinz 35W II/1; Horny Hornyphon; (ID = 570735) Radio
Use red slider bar for more.
Prinz 35W II/1; Horny Hornyphon; (ID = 228722) Radio
Horny Hornyphon;: Prinz 35W II/1 [Radio] ID = 228722 480x640
Select picture or schematic to display from thumbnails on the right and click for download.
For model Prinz 35W II/1, Horny (Hornyphon); Wien:
Hornyphon Prinz 35W

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1934–1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: AK1 E444 E443H 506
Main principle Superheterodyne (common); ZF/IF 128 kHz; Reflex
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Prinz 35W II/1 - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Notes Reflex; Export Schweiz (Sch=Thali)
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
