- Country
- United States of America (USA)
- Manufacturer / Brand
- Howard Radio Company; Chicago (IL)
- Year
- 1937
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 44481
Scanned from the Radio Retailing March 1937.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Main principle
- Superhet with RF-stage; ZF/IF 465 kHz; 3 AF stage(s)
- Tuned circuits
- 9 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 15 inch = 38.1 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 214 - Howard Radio Company; Chicago
- Shape
- Console with any shape - in general
- Notes
- BC (540 - 1700 kHz), TROP (1700 - 5500 kHz) and SW (5.5 - 18.0 MHz) bands. Tuning eye. Push-pull audio amplifier.
- External source of data
- Ernst Erb
- Source of data
- Collector's Guide to Antique Radios 4. Edition
- Circuit diagram reference
- Rider's Perpetual, Volume 8 = 1937 and before
- Mentioned in
- Pre-War Consoles
- Literature/Schematics (1)
- Radio Retailing (Radio & Television R.) (March 1937.)
