C-36

C-36; Iberia Radio SA; (ID = 614971) Radio

C-36; Iberia Radio SA; (ID = 614967) Radio

C-36; Iberia Radio SA; (ID = 614968) Radio

C-36; Iberia Radio SA; (ID = 614969) Radio

C-36; Iberia Radio SA; (ID = 614970) Radio

C-36; Iberia Radio SA; (ID = 614972) Radio
C-36; Iberia Radio SA; (ID = 987304) Radio C-36; Iberia Radio SA; (ID = 987305) Radio
C-36; Iberia Radio SA; (ID = 987306) Radio C-36; Iberia Radio SA; (ID = 614973) Radio
Use red slider bar for more.
C-36; Iberia Radio SA; (ID = 987304) Radio
Iberia Radio SA;: C-36 [Radio] ID = 987304 933x615
Select picture or schematic to display from thumbnails on the right and click for download.
For model C-36, Iberia Radio SA; Barcelona

Country:  Spain
Manufacturer / Brand:  Iberia Radio SA; Barcelona
Year: 1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH81 EF41 EAF42 EL41 EM80 EZ80
Main principle Superheterodyne (common); ZF/IF 472 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 100;125;150 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6.5 inch = 16.5 cm
Power out
from Radiomuseum.org Model: C-36 - Iberia Radio SA; Barcelona
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 540 x 340 x 250 mm / 21.3 x 13.4 x 9.8 inch
Notes

BC, Police band, 3 x SW.
Este aparato puede venir de fábrica con altavoz electrodinámico o de imán permanente. Ver esquema.
This equipment was sold with either electromagnetic or permanent magnet type loudspeaker. See schematic.

Serie ORO

Antena antiparasitaria

Teclado Mágico

Price in first year of sale 2'997.55 ESP
External source of data Ernst Erb
Source of data Radio Historia y Técnica, J.J.E.
Literature/Schematics (4) Anuncio La Vanguardia Española noviembre 1955
