Ferrophon IIIc-3 (3c-3)

Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 2005417) R-Player Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 2005187) R-Player
Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 2005188) R-Player Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 541672) R-Player
Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 171859) R-Player Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 309620) R-Player
Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 309621) R-Player Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 309623) R-Player
Use red slider bar for more.
Ferrophon IIIc-3 ; Ihle, Max; Kulmbach (ID = 2005417) R-Player
Ihle, Max; Kulmbach: Ferrophon IIIc-3 [R-Player] ID = 2005417 1400x850
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ferrophon IIIc-3 (3c-3), Ihle, Max; Kulmbach und Grundmühle

Country:  Germany
Manufacturer / Brand:  Ihle, Max; Kulmbach und Grundmühle
Year: 1953 Category: Sound/Video Recorder and/or Player
Valves / Tubes 4: EF40 EF40 EL41 AZ41
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 10 W (unknown quality)
from Radiomuseum.org Model: Ferrophon IIIc-3 - Ihle, Max; Kulmbach und Grundm
Material Leather / canvas / plastic - over other material
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 630 x 450 x 230 mm / 24.8 x 17.7 x 9.1 inch
Notes

3 Bandgeschwindigkeiten. LS im Deckel.
Wurde auch unter gleichen Namen von Loewe-Opta vertrieben.

Net weight (2.2 lb = 1 kg) 33 kg / 72 lb 11 oz (72.687 lb)
Price in first year of sale 2'505.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1953/54

Model page created by Bernd P. Kieck. See "Data change" for further contributors.



All listed radios etc. from Ihle, Max; Kulmbach und Grundmühle
Here you find 11 models, 6 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
