Sweet-Clock R27

Sweet-Clock R27; Imperial Rundfunk (ID = 327773) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 327772) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 1118041) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 1118042) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 1118043) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 1118044) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 1118045) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 1118046) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 1118047) Radio

Sweet-Clock R27; Imperial Rundfunk (ID = 1118077) Radio
Sweet-Clock R27; Imperial Rundfunk (ID = 813913) Radio Sweet-Clock R27; Imperial Rundfunk (ID = 988929) Radio
Sweet-Clock R27; Imperial Rundfunk (ID = 324096) Radio Sweet-Clock R27; Imperial Rundfunk (ID = 498998) Radio
Sweet-Clock R27; Imperial Rundfunk (ID = 988927) Radio Sweet-Clock R27; Imperial Rundfunk (ID = 1996654) Radio
Use red slider bar for more.
Sweet-Clock R27; Imperial Rundfunk (ID = 813913) Radio
Imperial Rundfunk: Sweet-Clock R27 [Radio] ID = 813913 845x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sweet-Clock R27, Imperial Rundfunk und Fernseh (Kuba-Imperial, auch General Electric); Osterode/Harz, Hemmingen:
Kuba Imperial Report 2/66 - Sammlung Funkhistorisches Archiv der GFGF e.V.

Country:  Germany
Manufacturer / Brand:  Imperial Rundfunk und Fernseh (Kuba-Imperial, auch General Electric); Osterode/Harz, Hemmingen
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF106 AF121 AF126 AF126 AF121 BC130 BC130 AC178 AC179 AC153 AA112 AA112 AA113 ZF8,2
Main principle Superheterodyne (common); ZF/IF 10700 kHz
Tuned circuits 11 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: Sweet-Clock R27 - Imperial Rundfunk und Fernseh
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 235 x 260 x 190 mm / 9.3 x 10.2 x 7.5 inch
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
External source of data erb
Source of data Handbuch VDRG 1967/1968 / Radiokatalog Band 2, Ernst Erb


All listed radios etc. from Imperial Rundfunk und Fernseh (Kuba-Imperial, auch General Electric); Osterode/Harz, Hemmingen
Here you find 437 models, 410 with images and 211 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
