VZ404

Country:  Italy
Manufacturer / Brand:  Incar S.r.l.; Vercelli
Year: 1955/1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4:
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Loudspeaker -Loudspeaker incorporated, but system not known.
Power out
from Radiomuseum.org Model: VZ404 - Incar S.r.l.; Vercelli
Material Bakelite or Plastics (type unknown)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 200 x 120 x 60 mm / 7.9 x 4.7 x 2.4 inch
Source of data Guida Pratica Antique Radio (1) 1999

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Incar S.r.l.; Vercelli
Here you find 86 models, 49 with images and 43 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
