Lectron Serie 2000 2005
Use red slider bar for more.
INELCO Industria: Lectron Serie 2000 2005 [Kit] ID = 1723388 933x713
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1974 ? | Category: Kit (Parts plus instruction) or building instructions only | ||||
| Semiconductors (the count is only for transistors) | 2: AC125 BC307 |
|---|
| Main principle | Audio-Amplification; 2 AF stage(s) |
|---|---|
| Wave bands | - without |
| Details | |
| Power type and voltage | Dry Batteries / 1x 9 Volt |
| Loudspeaker | |
| Power out | |
| from Radiomuseum.org | Model: Lectron Serie 2000 2005 - INELCO Industria Elettronica |
| Material | Plastics (no bakelite or catalin) |
| Notes | Ergänzungspackung 2005 mit Bausteinen; damit können weitere Experimente des (italienischen) Systems Lectron serie 2000 (Basis: Lectron Buchlabor) durchgeführt werden. Der Titel der Packung ist "Amplificatore telefonico - rivelatore di pioggia" (Telefonverstärker - Regendetektor). |
Model page created by Günther Stabe † 19.8.20. See "Data change" for further contributors.
