Columbus 38GW

Columbus 38GW; Ingelen, (ID = 645651) Radio

Columbus 38GW; Ingelen, (ID = 308080) Radio

Columbus 38GW; Ingelen, (ID = 9345) Radio

Columbus 38GW; Ingelen, (ID = 991701) Radio
Use red slider bar for more.
Columbus 38GW; Ingelen, (ID = 645651) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Austria
Manufacturer / Brand:  Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Brand

Elektrot.Fabrik Ludwig Neumann
Year: 1937/1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: EK2 EF5 CBL1 CY1 C12 U1220-6_8-pin(P8A)
Main principle Superheterodyne (common); ZF/IF 128,5 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110; 130; 150; 220 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: Columbus 38GW - Ingelen, Elektrotechnische
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes
Price in first year of sale 209.00 RM
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
