Weltblick 611TR Nr. > 306.001

Weltblick 611TR; Ingelen, (ID = 137624) Television

Weltblick 611TR; Ingelen, (ID = 137625) Television

Weltblick 611TR; Ingelen, (ID = 137626) Television

Weltblick 611TR; Ingelen, (ID = 137627) Television
Weltblick 611TR; Ingelen, (ID = 421817) Television Weltblick 611TR; Ingelen, (ID = 421818) Television
Use red slider bar for more.
Weltblick 611TR; Ingelen, (ID = 421817) Television
Ingelen,: Weltblick 611TR [Television] ID = 421817 679x512
Select picture or schematic to display from thumbnails on the right and click for download.
For model Weltblick 611TR Nr. > 306.001, Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien

Country:  Austria
Manufacturer / Brand:  Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Brand

Elektrot.Fabrik Ludwig Neumann
Year: 1965 Category: Television Receiver (TV) or Monitor
Valves / Tubes 15: PCC189 PCF86 PC88 PC86 PFL200 PCL86 PCH200 PCF80 PF86 PCL85 PCF802 PL500 PY88 DY86 A59-16W
Semiconductors (the count is only for transistors) 6:
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Weltblick 611TR [Nr. > 306.001] - Ingelen, Elektrotechnische
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 600 x 550 x 395 mm / 23.6 x 21.7 x 15.6 inch
Net weight (2.2 lb = 1 kg) 34 kg / 74 lb 14.2 oz (74.89 lb)
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
