Blu-RX-S-2000-EP

IRME (Industrie Radio Meccaniche Elettriche); Roma

Data
Forum
Pictures
Collections

  • Year
  • 1969 ??
  • Category
  • Commercial Receiver (may include amateur bands)
  • Radiomuseum.org ID
  • 224924

 Technical Specifications

  • Number of Transistors
  • 34
  • Main principle
  • Superhet, double/triple conversion
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12; 24 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch
  • Power out
  • 4 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Blu-RX-S-2000-EP - IRME Industrie Radio
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 440 x 170 x 240 mm / 17.3 x 6.7 x 9.4 inch
  • Notes

  • Le frequenze coperte sono: a= 2182 kHz, SW: b= 1600 - 4200 kHz, c= MW: 520 - 1600 kHz, d= LW: 200 - 400kHz.

    Le frequenze a e b sono a doppia conversione di frequenza, 1ª IF = 455 kHz, 2ª IF = 1400 kHZ, mentre c e d sono a singola conversione con IF = 455 kHz.



  • Net weight (2.2 lb = 1 kg)
  • 8 kg / 17 lb 9.9 oz (17.621 lb)
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Fabio Masetti. See "Data change" for further contributors.
