Polo VR50

Irradio; Milano

  • Year
  • 1976 ?
  • Category
  • Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
  • Radiomuseum.org ID
  • 201987

 Technical Specifications

  • Number of Transistors
  • 1
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 10 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
  • Power out
  • 0.8 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Polo VR50 - Irradio; Milano
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 315 x 140 x 175 mm / 12.4 x 5.5 x 6.9 inch
  • Notes
  • Televisore con tubo da 4,5",jn bianco e nero, riceve i canali VHF I, VHF III, UHF. Presa per alimentazione esterna a 12 V,1 A. Può essere anche alimentato con 10 batterie ricaricabili, e quando l'apparecchio è alimentato dalla rete, spengendolo dal pulsante di accensione e spostando il medesimo sulla sinistra, si ricaricano automaticamente le batterie. Consumo 20 W/h, EAT sul tubo 6,8 KV.
  • Author
  • Model page created by Fabio Masetti. See "Data change" for further contributors.
