HiFi-Superkompaktbox SKB 60 N
Isophon, E. Fritz & Co. GmbH.; Berlin
- Country
- Germany
- Manufacturer / Brand
- Isophon, E. Fritz & Co. GmbH.; Berlin
- Year
- 1976 ??
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 262152
-
- Brand: Isophon
Isophon - Emblem leider verloren
Interfunk Katalog 1976
Tieftoener 203mm
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- 3 Loudspeakers
- Power out
- 40 W (60 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: HiFi-Superkompaktbox SKB 60 N - Isophon, E. Fritz & Co. GmbH.;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 440 x 250 x 200 mm / 17.3 x 9.8 x 7.9 inch
- Notes
-
Isophon SKB 60 N (Nußbaumfarben)
3-Weg-HiFi-Superkompaktbox, geschlossene Ausführung,
Übertragungsbereich 35-20.000Hz, Nennbelastbarkeit 40 Watt, Musikbelastbarkeit 60 Watt, drei Lautsprecher, Tieftöner 203mm, Mitteltöner 100mm und Kugelkalottenhochtöner.
Gehäuse Nußbaumfarben
- Price in first year of sale
- 356.00 DM
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
