Electronic 2000 5112 03 11; ITT Schaub-Lorenz (ID = 2108997) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  ITT Schaub-Lorenz
Year: 1968/1969 Category: Television Receiver (TV) or Monitor
Valves / Tubes 9: PCL86 PCH200 PFL200 PCF802 PCL805 PY88 PL504 DY802 A51-10W
Semiconductors (the count is only for transistors) 10: AF239 BF181 AF239 AF106 AF106 BFY39 BF167 BF176 BF173 BF133
Main principle Superheterodyne (common); ZF/IF 38900 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Electronic 2000 5112 03 11 - ITT Schaub-Lorenz
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 519 x 379 x 325 mm / 20.4 x 14.9 x 12.8 inch
Notes

Tragbares 51cm S/W Fernsehgerät ITT-Schaub Lorenz Electronic 2000.

Ausführung: Type 5112 03 11 Rio-Palisander, Front weiss

Net weight (2.2 lb = 1 kg) 19 kg / 41 lb 13.6 oz (41.85 lb)
Literature/Schematics (1) -- Original-techn. papers.
