For model Golf automatic 100 52140115, ITT Schaub-Lorenz Wien:
Image taken from polish online auction portal .allegro.pl. Auction number: _6663485491

Country:  Austria
Manufacturer / Brand:  ITT Schaub-Lorenz Wien
Year: 1968/1969 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF106 AF124 AF136 AF137 AF138 BC172 BC252 AC178 AC179
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 x 1,5 / 2 x 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Golf automatic 100 52140115 - ITT Schaub-Lorenz Wien
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 278 x 187 x 89 mm / 10.9 x 7.4 x 3.5 inch
Notes

Mit Netzanschlußgerät ITT NG3000 auch an 220 V~ zu betreiben.

Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
