Flirt 100

Flirt 100 ; ITT-KB; Foots Cray, (ID = 1304437) Radio Flirt 100 ; ITT-KB; Foots Cray, (ID = 1304438) Radio
Flirt 100 ; ITT-KB; Foots Cray, (ID = 1304439) Radio Flirt 100 ; ITT-KB; Foots Cray, (ID = 1304440) Radio
Flirt 100 ; ITT-KB; Foots Cray, (ID = 1304441) Radio Flirt 100 ; ITT-KB; Foots Cray, (ID = 1304442) Radio
Use red slider bar for more.
Flirt 100 ; ITT-KB; Foots Cray, (ID = 1304437) Radio
ITT-KB; Foots Cray,: Flirt 100 [Radio] ID = 1304437 933x652
Select picture or schematic to display from thumbnails on the right and click for download.
For model Flirt 100, ITT-KB; Foots Cray, Kent; (ITT Consumer Products (UK) Ltd. ex Kolster-Brandes)

Country:  Great Britain (UK)
Manufacturer / Brand:  ITT-KB; Foots Cray, Kent; (ITT Consumer Products (UK) Ltd. ex Kolster-Brandes)
Year: 1976 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: CS9016 CS9011 CS9011 CS9014 CS1978 CS6206 CS6207
Main principle Superheterodyne (common); ZF/IF 470 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 9 cm = 3.5 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Flirt 100 - ITT-KB; Foots Cray, Kent; ITT
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 164 x 92 x 47 mm / 6.5 x 3.6 x 1.9 inch
Notes

Avaiable in a variety of colours

Gain variants of Transistors is suffix used

F CS9016-E, F CS9011-E, F CS9011-F, F CS9014-B, F CS1978-B, F CS6206, F CS6207

Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)
Source of data - - Manufacturers Literature

Model page created by Mike Edwards. See "Data change" for further contributors.
