For model KA2015, ITT-KB; Foots Cray, Kent; (ITT Consumer Products (UK) Ltd. ex Kolster-Brandes):
photo from service manual

Country:  Great Britain (UK)
Manufacturer / Brand:  ITT-KB; Foots Cray, Kent; (ITT Consumer Products (UK) Ltd. ex Kolster-Brandes)
Year: 1974 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 28: BF240 BC172 BC236 BC125 BC126 BT101 TIP41 TIP42
Main principle Super-Heterodyne (Super in general); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details Changer (Record changer); Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 220 - 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 15 W (max.)
from Radiomuseum.org Model: KA2015 - ITT-KB; Foots Cray, Kent; ITT
Material Various materials
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 632 x 203 x 404 mm / 24.9 x 8 x 15.9 inch
Notes

Stereo Decoder IC; SN76110-07

Semiconductors several times available;

Record Changer BSR C141R with cartridge BSR SC5M fitted with stylus ST19D.

FM coverage 87MHz to 101.5MHz

Model page created by Mike Edwards. See "Data change" for further contributors.
