• Country
• Great Britain (UK)

• Manufacturer / Brand
• ITT-KB; Foots Cray, Kent; (ITT Consumer Products (UK) Ltd. ex Kolster-Brandes)

• Year
• 1978 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 150539

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• 2SC784 2SC785 2SC381 CS1312 2SC381 CS1312 LM1410 LM1404 LM1403

• Main principle
• Superheterodyne (common); ZF/IF 470/10700 kHz

• Tuned circuits
• 5 AM circuit(s)     7 FM circuit(s)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Dry Batteries / 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 0.4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Tiny Super 300 - ITT-KB; Foots Cray, Kent; ITT

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 223 x 152 x 55 mm / 8.8 x 6 x 2.2 inch

• Notes

• ITT Tiny Super 300;

  Wavebands: LW 145 - 260 kHz, MW 510 - 1605 kHz, FM 87.5 - 104 MHz.

  Elliptical loudspeaker 6.5 x 10.5 cm.

• Net weight (2.2 lb = 1 kg)
• 0.850 kg / 1 lb 14 oz (1.872 lb)

• Literature/Schematics (1)
• - - Manufacturers Literature (ITT Service-Information)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
