FM-Tuner 312-0012

FM-Tuner 312-0012; Görler, J. K.; (ID = 1724119) mod-past25

FM-Tuner 312-0012; Görler, J. K.; (ID = 1724120) mod-past25
Use red slider bar for more.
FM-Tuner 312-0012; Görler, J. K.; (ID = 1724119) mod-past25
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Görler, J. K.; Berlin (Meuselwitz, Mannheim, Brühl)
Year: 1964 Category: Radio module post 1925 (not a part, not a key)
Semiconductors (the count is only for transistors) 2:
Main principle RF Converter/Adapter (not voltage converter); ZF/IF 10700 kHz
Tuned circuits 5 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Powered by external power supply or a main unit. / DC 10 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: FM-Tuner 312-0012 - Görler, J. K.; Berlin
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 80 x 40 x 31 mm / 3.1 x 1.6 x 1.2 inch
Notes

Die elektrischen Daten entsprechen dem UKW-Tuner 312-0036, nur ist der Variometerantrieb als Seilzug ausgebildet.

Mentioned in -- Original-techn. papers.

Model page created by Manfred Rauschen. See "Data change" for further contributors.
