Rauschsperre 326-0008

Rauschsperre 326-0008; Görler, J. K.; (ID = 1709288) mod-past25
Use red slider bar for more.
Rauschsperre 326-0008; Görler, J. K.; (ID = 1709288) mod-past25
Görler, J. K.;: Rauschsperre 326-0008 [mod-past25] ID = 1709288 933x790
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rauschsperre 326-0008, Görler, J. K.; Berlin (Meuselwitz, Mannheim, Brühl)

Country:  Germany
Manufacturer / Brand:  Görler, J. K.; Berlin (Meuselwitz, Mannheim, Brühl)
Year: 1968 ? Category: Radio module post 1925 (not a part, not a key)
Semiconductors (the count is only for transistors) 1: BC147
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Rauschsperre 326-0008 - Görler, J. K.; Berlin
Material Printed Circuit Board
Shape Chassis only or for «building in»
Dimensions (WHD) 47.5 x 36.2 x 25 mm / 1.9 x 1.4 x 1 inch
Notes

Rauschsperre zur Görler UKW-Tuner Baugruppenreihe 326-0008
zur Anschaltung an den Görler ZF-Verstärker 322-0030.
Die Rauschsperre ermöglicht die Unterdrückung des zwischen den Sendern auftretenden Rauschens, als auch eine definierte Anzeige der Feldstärke.

Model page created by Manfred Rauschen. See "Data change" for further contributors.
