• Year
  • 1978/1979
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 185241

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Batteries (any type) / 220/ ? x 1,5 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Radio-Recorder KR410 - Kapsch & Söhne KS, Telephon-
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 327 x 222 x 100 mm / 12.9 x 8.7 x 3.9 inch
  • Notes
  • Kapsch KR410 Radiorecorder;
    Analog Schaltuhr.
  • Mentioned in
  • -- Original prospect or advert ((A) Kapsch Geräteprogramm 1978/79)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
