Viennastar 500 Portable

Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134951) Television

Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134952) Television

Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134954) Television

Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134955) Television
Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134950) Television Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 135001) Television
Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134995) Television Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134996) Television
Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134997) Television
Use red slider bar for more.
Viennastar 500 Portable; Kapsch & Söhne KS, (ID = 134950) Television
Kapsch & Söhne KS,: Viennastar 500 Portable [Television] ID = 134950 506x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Viennastar 500 Portable, Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien

Country:  Austria
Manufacturer / Brand:  Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien
Year: 1970 ?? Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: 310EUB4
Semiconductors (the count is only for transistors) 29:
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Line / Batteries (any type) / 220 / 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 110 cm = 43.3 inch
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: Viennastar 500 Portable - Kapsch & Söhne KS, Telephon-
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes

VHF & UHF. Hergestellt in Fernost.

Siehe auch Quelle Universum SK-2605 Bestell Nr. 05052

Source of data -- Collector info (Sammler) / Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Alexander Fuchs. See "Data change" for further contributors.



All listed radios etc. from Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien
Here you find 605 models, 497 with images and 373 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
