Silelis (Shiljalis) 402D-1E

Silelis 402D-1E; Kauno Radijo Gamykla (ID = 830325) Television Silelis 402D-1E; Kauno Radijo Gamykla (ID = 830327) Television
Silelis 402D-1E; Kauno Radijo Gamykla (ID = 830328) Television Silelis 402D-1E; Kauno Radijo Gamykla (ID = 830329) Television
Silelis 402D-1E; Kauno Radijo Gamykla (ID = 830332) Television Silelis 402D-1E; Kauno Radijo Gamykla (ID = 830335) Television
Silelis 402D-1E; Kauno Radijo Gamykla (ID = 830338) Television
Use red slider bar for more.
Silelis 402D-1E; Kauno Radijo Gamykla (ID = 830325) Television
Kauno Radijo Gamykla: Silelis 402D-1E [Television] ID = 830325 926x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Silelis (Shiljalis) 402D-1E, Kauno Radijo Gamykla (KRG), Kaunas

Country:  Lithuania (Lithuania, Vilnius)
Manufacturer / Brand:  Kauno Radijo Gamykla (KRG), Kaunas
alternative name

Banga - Lithuania TV sets industrial union
Year: 1980 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: 16ЛК1Б
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Line / Batteries (any type) / 110; 127; 220 / 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: Silelis 402D-1E - Kauno Radijo Gamykla KRG,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 230 x 150 x 250 mm / 9.1 x 5.9 x 9.8 inch
Notes Small black/white television VHF/UHF.Picture size 92 x 116 mm. Cord for connection to car battery (- ground). This set was created for the European standard (type Shiljalis 402D-1E is indicated on the handle). The Russian markings (type 402D-1S) have been replaced by English on the front of the set (off/volume,contrast,brightness). There is also a version for the American standard (type 402D-1A indicated on the handle)
Net weight (2.2 lb = 1 kg) 3.9 kg / 8 lb 9.4 oz (8.59 lb)
Source of data -- Original prospect or advert

Model page created by Armand Verboven. See "Data change" for further contributors.
