Rigonda M (VL-100M) (VL100M)

Rigonda M ; Mezon Works, (ID = 179667) Television Rigonda M ; Mezon Works, (ID = 179668) Television
Rigonda M ; Mezon Works, (ID = 179669) Television Rigonda M ; Mezon Works, (ID = 179670) Television
Rigonda M ; Mezon Works, (ID = 183705) Television Rigonda M ; Mezon Works, (ID = 186166) Television
Rigonda M ; Mezon Works, (ID = 186550) Television Rigonda M ; Mezon Works, (ID = 752575) Television
Rigonda M ; Mezon Works, (ID = 752576) Television Rigonda M ; Mezon Works, (ID = 1190285) Television
Use red slider bar for more.
Rigonda M ; Mezon Works, (ID = 179667) Television
Mezon Works,: Rigonda M [Television] ID = 179667 439x439
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rigonda M (VL-100M) (VL100M), Mezon Works, Leningrad:
Ebay UK ynos123 5861702370

Country:  Soviet Union
Manufacturer / Brand:  Mezon Works, Leningrad
Year: 1976 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 1:
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Line / Batteries (any type) / 220 / 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Rigonda M - Mezon Works, Leningrad
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 210 x 150 x 230 inch / 5334 x 3810 x 5842 mm
Notes Portable Russian B/W TV, with wideband Tuner working Band I-V without a Band selector. Producibled in some others Russia factories as "Elektronika VL-100" (Chmelnickij "Kation" Works, Poltava Works, one of Moscow TV Works). In Great Britain TV was saled as "Rigonda-M","Rigonda VL-100","Rigonda VL-100M".
Name "VL-100" - its for 100 years Vladimir Lenin anniversary.
Net weight (2.2 lb = 1 kg) 4.8 kg / 10 lb 9.2 oz (10.573 lb)
Collectors' prices
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Mezon Works, Leningrad
Here you find 10 models, 10 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
