• Country
• United States of America (USA)

• Manufacturer / Brand
• Kent Radio; (where?)

• Year
• 1939 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 182006

• Number of Tubes
• 3

• Valves / Tubes
• 25B8GT 50L6GT 35Z5GT

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Metal case

• from Radiomuseum.org
• Model: 402-A - Kent Radio; where?

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 170 x 130 x 100 mm / 6.7 x 5.1 x 3.9 inch

• Notes

• Another metal "Ivory" finish cabinet version is the Arvin 402A.

• Net weight (2.2 lb = 1 kg)
• 1.560 kg / 3 lb 7 oz (3.436 lb)

• Mentioned in
• Collector's Guide to Antique Radios (7th Edition)

• Author
• Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
