800 G

800 G; Klarmax-Radio; (ID = 2396791) Radio 800 G; Klarmax-Radio; (ID = 2396792) Radio
800 G; Klarmax-Radio; (ID = 2396793) Radio 800 G; Klarmax-Radio; (ID = 2396794) Radio
800 G; Klarmax-Radio; (ID = 2396795) Radio 800 G; Klarmax-Radio; (ID = 2396796) Radio
800 G; Klarmax-Radio; (ID = 2396797) Radio 800 G; Klarmax-Radio; (ID = 2396798) Radio
800 G; Klarmax-Radio; (ID = 2396799) Radio
Use red slider bar for more.
800 G; Klarmax-Radio; (ID = 2396791) Radio
Klarmax-Radio;: 800 G [Radio] ID = 2396791 933x525
Select picture or schematic to display from thumbnails on the right and click for download.
For model 800 G, Klarmax-Radio; Asencio Quirant Gonzalvez; Elche

Country:  Spain
Manufacturer / Brand:  Klarmax-Radio; Asencio Quirant Gonzalvez; Elche
Year: 1945 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: EF9 ECH3 EBC3 EL3N AZ1
Main principle Super-Heterodyne (Super in general)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 800 G - Klarmax-Radio; Asencio Quirant
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 490 x 330 x 270 mm / 19.3 x 13 x 10.6 inch

Model page created by Carlos Sempere-Carrión. See "Data change" for further contributors.



All listed radios etc. from Klarmax-Radio; Asencio Quirant Gonzalvez; Elche
Here you find 16 models, 15 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
