Gram Desconocida-3 Unknown

Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161169) Radio Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161476) Radio
Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161477) Radio Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161478) Radio
Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161479) Radio Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161480) Radio
Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161481) Radio Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161482) Radio
Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161483) Radio
Use red slider bar for more.
Gram Desconocida-3 Unknown; Klarmax-Radio; (ID = 2161169) Radio
Klarmax-Radio;: Gram Desconocida-3 Unknown [Radio] ID = 2161169 940x525
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gram Desconocida-3 Unknown, Klarmax-Radio; Asencio Quirant Gonzalvez; Elche

Country:  Spain
Manufacturer / Brand:  Klarmax-Radio; Asencio Quirant Gonzalvez; Elche
Year: 1945–1948 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A8GT 6K7GT 6Q7GT 6V6GT 5Y3GT
Main principle Super-Heterodyne (Super in general)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Gram Desconocida-3 Unknown - Klarmax-Radio; Asencio Quirant
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 530 x 350 x 270 mm / 20.9 x 13.8 x 10.6 inch

Model page created by Carlos Sempere-Carrión. See "Data change" for further contributors.



All listed radios etc. from Klarmax-Radio; Asencio Quirant Gonzalvez; Elche
Here you find 16 models, 15 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
