Pulse Millivoltmeter V4-1A (В4-1A)

Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316577) Equipment

Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316578) Equipment

Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316580) Equipment

Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316581) Equipment

Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316582) Equipment
Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316151) Equipment Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316152) Equipment
Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316153) Equipment Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316154) Equipment
Use red slider bar for more.
Pulse Millivoltmeter V4-1A ; Tallinn Punane RET (ID = 1316151) Equipment
Tallinn Punane RET: Pulse Millivoltmeter V4-1A [Equipment] ID = 1316151 800x598
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pulse Millivoltmeter V4-1A (В4-1A), Tallinn Punane RET Radio Works

Country:  Estonia (Eesti, Tallinn)
Manufacturer / Brand:  Tallinn Punane RET Radio Works
Year: 1962 Category: Service- or Lab Equipment
Valves / Tubes 7: СГ1П 6Ц4П 1Б5-9 6Н2П 6Х2П 6Ж5П 6Ж1П 6Ж1П 6Ж1П
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Pulse Millivoltmeter V4-1A - Tallinn Punane RET Radio Works
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 310 x 215 x 195 mm / 12.2 x 8.5 x 7.7 inch
Notes

Messbereiche:

Ohne Spannungsteiler: 0 - 10 - 30 - 100 - 1000 - 3000 mV

Mit Spannungsteiler: 0 - 1 - 3 - 10 - 30 - 100 - 300 V

Frequenzbereich: 30Hz - 500 kHz (sinus)

Eingangswiderstand bei 50Hz: >= 1MOhm

Eingangskapazität: =< 10pF

Im Tastkopf ist eine Pentode 6j1p (6Ж1П) eingebaut.



Net weight (2.2 lb = 1 kg) 7.8 kg / 17 lb 2.9 oz (17.181 lb)
Collectors' prices
Mentioned in Осипов К.Д., Пасынков В.В. - Справочник По Радиоизмерительным Приборам - Том 5, 1964

Model page created by Chris Lepiarczyk. See "Data change" for further contributors.
