For model 38343 Art.-Nr. 826/936, Körting-Radio; Leipzig, später Grassau

Country:  Germany
Manufacturer / Brand:  Körting-Radio; Leipzig, später Grassau
alternative name

Dietz & Ritter GmbH, Dr.
Year: 1979 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 12:
Main principle Superheterodyne (common); ZF/IF 455 / 10700 kHz
Tuned circuits 5 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: 38343 Art.-Nr. 826/936 - Körting-Radio; Leipzig, später
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 606 x 175 x 155 mm / 23.9 x 6.9 x 6.1 inch
Notes

UKW manuelle Abstimmung oder 4 Fixtasten. Anschlußmöglichkeit für Plattenspieler, Tonbandgerät und Zusatzlautsprecher (15 Ohm). Ovallautsprecher 10 x 18 cm. Leistungsaufnahme 6 Watt. Art. Nr.: 826/936

Exportversion des Meiningen 2003  von VEB Robotron Zella-Mehlis.

Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Mentioned in -- Schematic

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.
