For model Cyclo-Super S2401WL, Körting-Radio; Leipzig, später Grassau

Country:  Germany
Manufacturer / Brand:  Körting-Radio; Leipzig, später Grassau
alternative name

Dietz & Ritter GmbH, Dr.
Year: 1933/1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: RENS1234 RENS1254 RES964 RGN1064
Main principle Super-Heterodyne (Super in general); ZF/IF 430 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Cyclo-Super S2401WL - Körting-Radio; Leipzig, später
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 420 x 530 x 300 mm / 16.5 x 20.9 x 11.8 inch
Collectors' prices
Source of data Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung


All listed radios etc. from Körting-Radio; Leipzig, später Grassau
Here you find 721 models, 567 with images and 416 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Körting-Radio;: Cyclo-Super S2401WL
Threads: 1 | Posts: 1
Hits: 1394     Replies: 0
korting: S2401WL; Cyclo-Super - Weight of the unit
Robert Sarbell
11.Nov.08
  1

Dear colleagues,

Would some member please be kind enough to identify the weight of the variant models - with or without the built-in independently powered dynamic loudspeaker (PM) OR the electromagnetic loudspeaker?

Also, provide the diameter of the speaker.

Respectfully,

Robert
