• Year
  • 1948–1950
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 15531

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 472 kHz
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Troubadour 49 83-66-500 - Krefft AG, W.; Gevelsberg
  • Dimensions (WHD)
  • 585 x 360 x 285 mm / 23 x 14.2 x 11.2 inch
  • Notes
  • var.BBr.; [572B]
  • Net weight (2.2 lb = 1 kg)
  • 16 kg / 35 lb 3.9 oz (35.242 lb)
  • Price in first year of sale
  • 575.00 DM
  • External source of data
  • E. Erb 3-907007-36-0
