11-7A (11-7)

11-7A ; Kriesler Radio (ID = 164058) Radio

11-7A ; Kriesler Radio (ID = 164059) Radio

11-7A ; Kriesler Radio (ID = 164060) Radio
11-7A ; Kriesler Radio (ID = 2360925) Radio 11-7A ; Kriesler Radio (ID = 163869) Radio
11-7A ; Kriesler Radio (ID = 410993) Radio
Use red slider bar for more.
11-7A ; Kriesler Radio (ID = 2360925) Radio
Kriesler Radio: 11-7A [Radio] ID = 2360925 1400x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model 11-7A (11-7), Kriesler Radio Company; Newtown (Sydney)

Country:  Australia
Manufacturer / Brand:  Kriesler Radio Company; Newtown (Sydney)
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH35 6U7 6B6G 6V6GT 6X5GT
Main principle ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 220-260 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: 11-7A - Kriesler Radio Company;
Material Bakelite case
Shape Tablemodel, low profile (big size).
Notes

The speaker is mounted in the top, facing upwards and slightly angled towards the front.

Price in first year of sale 26.75 AUS £
External source of data Ray Robinson
Source of data -- Collector info (Sammler)
Literature/Schematics (1) - - Manufacturers Literature (Kriesler Technical Instructions)
Literature/Schematics (2) Australian Official Radio Service Manual AORSM (Volume 6, 1948, Page 266.)

Model page created by Ernst Erb. See "Data change" for further contributors.



All listed radios etc. from Kriesler Radio Company; Newtown (Sydney)
Here you find 837 models, 326 with images and 327 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Kriesler Radio: 11-7A
Threads: 1 | Posts: 2
Hits: 1563     Replies: 1
kriesler: Große Skalen an Australischen Radios
Wolfgang Scheida
22.Feb.06
  1 Liebe Sammler

Australische Radios fallen durch deutlich größere Skalen und eine andere Beschriftung derselben auf.
Kann jemand erklären was es damit auf sich hat?

MfG
Henning Oelkers
22.Feb.06
  2 Hallo, Herr Scheida,

die am Skalenrand vorhandenen Buchstabenkürzel dürften für die Australischen Bundesstaaten ( WA = Western Australia, SA = South Australia, QLD = Queensland, NSW = New South Wales ), sowie TAS = Tasmanien )stehen.

Allerdings ist für das Northern Territory keine Skalenmarkierung sichtbar.

Vielleicht weiss es ja jemand noch genauer.

Gruß aus Berlin,

Henning Oelkers


Kriesler Radio: 11-7A
End of forum contributions about this model
