At 6Z

Krundaal Davoli; Parma

Data
Forum
Pictures
Collections

  • Year
  • 1960 ??
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 304374

 Technical Specifications

  • Number of Transistors
  • 4
  • Main principle
  • Audio-Amplification
  • Power type and voltage
  • Storage and/or dry batteries / 12 / 4 x 4,5 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: At 6Z - Krundaal Davoli; Parma
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 220 x 80 x 100 mm / 8.7 x 3.1 x 3.9 inch
  • Notes

  • Amplificatore portatile per alimentazione a batteria da 12V o 4 batterie interne da 4,5V.

    Ingresso per microfono e uscita per altoparlante 10-20 ohm.

    Portable amplifier, power supply 12V car battery or 4 x 4.5V dry batteries.

    Microphone input, 10 to 20 ohm loudspeaker impedance.

  • Mentioned in
  • -- Collector info (Sammler)
  • Literature/Schematics (1)
  • -- Schematic (Schematic drawing glued inside the cabinet.)
  • Author
  • Model page created by Paolo De Pasqual. See "Data change" for further contributors.
