Puszta 57 Ch= 604 = Fidelio 57 4 LS

Puszta 57 Ch= 604 = Fidelio 57; Kuba Kuba-Imperial, (ID = 966886) Radio Puszta 57 Ch= 604 = Fidelio 57; Kuba Kuba-Imperial, (ID = 966887) Radio
Puszta 57 Ch= 604 = Fidelio 57; Kuba Kuba-Imperial, (ID = 966888) Radio Puszta 57 Ch= 604 = Fidelio 57; Kuba Kuba-Imperial, (ID = 1513713) Radio
Use red slider bar for more.
Puszta 57 Ch= 604 = Fidelio 57; Kuba Kuba-Imperial, (ID = 966886) Radio
Kuba Kuba-Imperial,: Puszta 57 Ch= 604 = Fidelio 57 [Radio] ID = 966886 379x366
Select picture or schematic to display from thumbnails on the right and click for download.
For model Puszta 57 Ch= 604 = Fidelio 57 4 LS, Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel:
Foto aus Auktion mit schriftlichem Einverständnis von Mitglied 'harleyniknak'

Country:  Germany
Manufacturer / Brand:  Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
alternative name

Imperial Kuba
Year: 1957/1958 Category: Broadcast Receiver - or past WW2 Tuner
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Puszta 57 Ch= 604 = Fidelio 57 [4 LS] - Kuba Kuba-Imperial, G.
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 810 x 850 x 440 mm / 31.9 x 33.5 x 17.3 inch
Notes

Nachtrag im Katalog 1957/58

Nordmende Chassis: Fidelio 57.

Net weight (2.2 lb = 1 kg) 31 kg / 68 lb 4.5 oz (68.282 lb)
Price in first year of sale 728.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1957/58 / Radiokatalog Band 2, Ernst Erb
