223V; Kungs Brand; (ID = 402654) Radio
Kungs Brand;: 223V [Radio] ID = 402654 700x493
Select picture or schematic to display from thumbnails on the right and click for download.
For model 223V, Kungs (Brand); Göteborg

Country:  Sweden
Manufacturer / Brand:  Kungs (Brand); Göteborg
alternative name

Kungsradio
Year: 1942 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH11 EBF11 EBC11 EL11 AZ11
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-260 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: 223V - Kungs Brand; Göteborg
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 445 x 270 x 215 mm / 17.5 x 10.6 x 8.5 inch
Net weight (2.2 lb = 1 kg) 9.6 kg / 21 lb 2.3 oz (21.145 lb)
Price in first year of sale 320.00 SEK
Collectors' prices
Source of data - - Data from my own collection

Model page created by Anders Söderström. See "Data change" for further contributors.
