Generador B.F. GA-900
LME Laboratorio de Metrologia Electrónica; Barcelona
- Country
- Spain
- Manufacturer / Brand
- LME Laboratorio de Metrologia Electrónica; Barcelona
- Year
- 1955 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 153883
Sacada del manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Generador B.F. GA-900 - LME Laboratorio de Metrologia
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 310 x 210 x 150 mm / 12.2 x 8.3 x 5.9 inch
- Notes
-
Laboratorio de Metrología Electrónica (LME), GA-900
Generador de BF, onda senoidal y cuadrada, 20 - 200.000 Hz en 4 bandas.
Precio: 5.970 pesetas. (Tarifa oficial de precios LME junio 1959)
- Net weight (2.2 lb = 1 kg)
- 8 kg / 17 lb 9.9 oz (17.621 lb)
- Mentioned in
- Tarifa oficial de precios LME junio 1959
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
