• Country
• Spain

• Manufacturer / Brand
• LME Laboratorio de Metrologia Electrónica; Barcelona

• Year
• 1958 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 169936

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• EA50 ECC82 ECC82 ECL80

• Number of Transistors

• Semiconductors
• Tr.Gl.=Metal-rectif.

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.5 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Volvamide Signal Tracer - LME Laboratorio de Metrologia

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 310 x 225 x 135 mm / 12.2 x 8.9 x 5.3 inch

• Notes

• Laboratorio de Metrología Electrónica (LME), Volvamide

  Voltímetro Electrónico y Signal Tracer

  Precio: 5.800 pesetas. (Tarifa oficial de precios LME junio 1959)

  EA50 en el interior de la sonda HF. EA50 inside HF probe.

• Net weight (2.2 lb = 1 kg)
• 6 kg / 13 lb 3.5 oz (13.216 lb)

• Mentioned in
• Tarifa oficial de precios LME junio 1959

• Literature/Schematics (1)
• -- Schematic (Catálogo LME 1963)

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
