Voltímetro Electrónico VT-5
LME Laboratorio de Metrologia Electrónica; Barcelona
- Country
- Spain
- Manufacturer / Brand
- LME Laboratorio de Metrologia Electrónica; Barcelona
- Year
- 1965
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 172516
Catálogo LME 1968-1969
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Number of Transistors
- 1
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Voltímetro Electrónico VT-5 - LME Laboratorio de Metrologia
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 165 x 230 x 130 mm / 6.5 x 9.1 x 5.1 inch
- Notes
- Impedancia de entrada: 11 MΩ.
Z input: 11 MΩ.
Precio en catálogo 1967: 6460 Pts (ESP).
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
