• Year
  • 1937 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 71677
    • alternative name: Wholesale Radio

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 456 kHz
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • AC/DC-set / 115 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • from Radiomuseum.org
  • Model: CC25 - Lafayette Radio & TV Corp; New
  • External source of data
  • Small & Specialty Manufacturers Radio Diagrams
  • Circuit diagram reference
  • Beitman Radio Diagrams Vol. 3, 1940
  • Author
  • Model page created by Hilmer Grunert. See "Data change" for further contributors.
