• Year
  • 1965 ??
  • Category
  • Amateur TRX: Transmitter/Receiver (and Transceiver)
  • Radiomuseum.org ID
  • 247437
    • alternative name: Wholesale Radio

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 10
  • Number of Transistors
  • 4
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 5745 / 455 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / AC: 117 / DC: 12 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 4 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Six Meters HA-460 - Lafayette Radio & TV Corp; New
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 12.125 x 5.125 x 9.25 inch / 308 x 130 x 235 mm
  • Notes
  • Mobile AM transceiver; 20 watts transmitter power input; Tuning range 50 to 52 MHz.

  • Net weight (2.2 lb = 1 kg)
  • 19 lb (19 lb 0 oz) / 8.626 kg
  • Price in first year of sale
  • 149.95 USD
  • Literature/Schematics (1)
  • -- Original-techn. papers.
