CRT Deflection Yoke DY123

CRT Deflection Yoke DY123; Lake/Elcom; (ID = 2498108) Misc
CRT Deflection Yoke DY123; Lake/Elcom; (ID = 2498107) Misc
Use red slider bar for more.
CRT Deflection Yoke DY123; Lake/Elcom; (ID = 2498107) Misc
Lake/Elcom;: CRT Deflection Yoke DY123 [Misc] ID = 2498107 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model CRT Deflection Yoke DY123, Lake/Elcom; Scarborough, ON

Country:  Canada
Manufacturer / Brand:  Lake/Elcom; Scarborough, ON
Year: 1967 Category: Miscellaneous (Other, Various) - see notes
Details
Loudspeaker
Power out
from Radiomuseum.org Model: CRT Deflection Yoke DY123 - Lake/Elcom; Scarborough, ON
Material Various materials
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 4 x 3 x 4 inch / 102 x 76 x 102 mm
Notes

Model is 110 degree Universal CRT Deflection Yoke.

Net weight (2.2 lb = 1 kg) 1 lb (1 lb 0 oz) / 0.454 kg
Mentioned in - - Manufacturers Literature
Literature/Schematics (1) -- Schematic

Model page created by Jack Sorensen. See "Data change" for further contributors.



All listed radios etc. from Lake/Elcom; Scarborough, ON
Here you find 5 models, 5 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
