5.5" B/W TV T-9041
Lenco Italiana; Osimo (AN)
- Country
- Italy
- Manufacturer / Brand
- Lenco Italiana; Osimo (AN)
- Year
- 1995 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 306802
Typ
- Number of Tubes
- 1
- Valves / Tubes
- 14SX3Y4
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Line plus power jack, mostly with battery or storage battery / 230 / DC 12-14 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 5.5" B/W TV T-9041 - Lenco Italiana; Osimo AN
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 180 x 160 x 220 mm / 7.1 x 6.3 x 8.7 inch
- Notes
-
Lenco 14 cm portable black/white TV, available in different colours (orange, red, blue, green)
- Net weight (2.2 lb = 1 kg)
- 1.8 kg / 3 lb 15.4 oz (3.965 lb)
- Author
- Model page created by Axel Paap. See "Data change" for further contributors.
