Oktâbr' (Oktiabr) {Октябрь}

Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272571) Radio

Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272572) Radio
Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272560) Radio Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272564) Radio
Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272569) Radio Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272562) Radio
Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272563) Radio Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272565) Radio
Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272566) Radio Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272567) Radio
Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272568) Radio Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 1439061) Radio
Use red slider bar for more.
Oktâbr' {Октябрь} ; Leningrad Metallic (ID = 272560) Radio
Leningrad Metallic: Oktâbr' {Октябрь} [Radio] ID = 272560 548x438
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oktâbr' (Oktiabr) {Октябрь}, Leningrad Metallic Works:
Thanks for Valery Charcenko, Russia

Country:  Soviet Union
Manufacturer / Brand:  Leningrad Metallic Works
Year: 1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: 6К3 6А7 6К3 6Б8С 6Е5С 6Н9С 6П6С 6П6С 5Ц4С
Main principle Superheterodyne (common); ZF/IF 465 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 9 W (unknown quality)
from Radiomuseum.org Model: Oktâbr' {Октябрь} - Leningrad Metallic Works
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 600 x 410 x 330 mm / 23.6 x 16.1 x 13 inch
Notes First class, rare and good quality early russian tube radio.
Net weight (2.2 lb = 1 kg) 20 kg / 44 lb 0.8 oz (44.053 lb)
Mentioned in E.A. Levitin "Radio sets" Moscow 1960
Literature/Schematics (1) Past Soviet Union magazine RADIO Nr.08 - 1954

Model page created by Zenonas Langaitis. See "Data change" for further contributors.
