Lesaphon Bermude LFR436

LESA ; Milano

  • Year
  • 1968 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 294481

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast only (MW).
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Line / Batteries (any type) / 110; 125; 160; 220 AC / 6 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
  • Power out
  • 3 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Lesaphon Bermude LFR436 - LESA ; Milano
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 360 x 130 x 210 mm / 14.2 x 5.1 x 8.3 inch
  • Notes
  • Lesa Lesaphon Bermude LFR436 - fonovaligia con radio AM - antenna interna in ferrite - controllo volume/tono - commutatore radio/phono - giradischi LESA 4 velocità 16/33/45/78 giri - testina con puntina in diamante girevole S/78.

  • Net weight (2.2 lb = 1 kg)
  • 1.6 kg / 3 lb 8.4 oz (3.524 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
