For model LW-4 Repwood, Lewol Mfg. Corp.; Chicago (IL)

Country:  United States of America (USA)
Manufacturer / Brand:  Lewol Mfg. Corp.; Chicago (IL)
Year: 1933 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 6D6 6C6 43 25Z5
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 110 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: LW-4 [Repwood] - Lewol Mfg. Corp.; Chicago IL
Material Special material, described in the notes.
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 10 x 7 x 4.75 inch / 254 x 178 x 121 mm
Notes

Repwood case.



External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 5 = ca. 1934 and before
