Inconnu - Unknown 1
LiRR, Les Ingéneurs Radio Réunis, A.-G. Delval; Paris
- Country
- France
- Manufacturer / Brand
- LiRR, Les Ingéneurs Radio Réunis, A.-G. Delval; Paris
- Year
- 1936 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 226362
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Details
- Visual Tuning Indicator pre Eye
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 220; 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 21 cm = 8.3 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Inconnu - Unknown 1 - LiRR, Les Ingéneurs Radio
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 390 x 460 x 290 mm / 15.4 x 18.1 x 11.4 inch
- Notes
-
Voir aussi modèle similaire 65.
Die Abstimmanzeige ist als mA-Meter mit Flächendarstellung (kein Zeiger) ausgeführt.
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by Manfred Rathgeb. See "Data change" for further contributors.
