• Country
• United States of America (USA)

• Manufacturer / Brand
• Lloyd's Electronics; Chicago, IL

• Year
• 1965 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 300468

• Number of Transistors
• 8

• Semiconductors
• 2SA29 2SA29 2SA29 2SA29 2SB95 2SB95 2SB56 2SB56

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• C: 4 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: 8 Transistor High Sensitivity TR-86L - Lloyd's Electronics; Chicago,

• Dimensions (WHD)
• 9 x 5 x 2 inch / 229 x 127 x 51 mm

• Notes

• Similar to other models listed under Browni

• Mentioned in
• Collector's Guide To TrR1 Bunis trans.94 (1996, page 148)

• Author
• Model page created by Aldo Andreani. See "Data change" for further contributors.
